Outside dimensions :
• Top 9cm ∅
• Height <10cm
Lid :
Function: gas exchange
• Maximum slot width 10 mm
• Lid can be opened for maintenance
Support anchors :
Function; anchoring the base, to prevent the product from being pushed
up or tilted.
• 11,5 x 11,5 cm
Tube connection :
• Between the notches suitable for tube 100 mm
• In the socket suitable for pipe 80 mm
• Sand-tight seal between end cap and pipe
